TWO SYMPTOMS:

Drawing fittings and pipe look disjointed, like that time an alien team of scientists were performing out-of-phase medical experiments on the Voyager crew.

Or, on the way into Revit, you get this error;

Error (must be addressed in order to continue)

Revit has experienced an unexpected error.  The operation has been cancelled to protect your project from corruption

Deleted element

When reporting the error, you may see this;

Hashtable head_table, Hashtable FLXpipeTable, List '1 listFtgs, flexpipes PipeTypeInfo ptInfo

Step 1a.3 - Fitting Exchange No replacement fitting name for 22E for Sched-10 Note: This could be any fitting or pipe type described in the error. If you click ok at each error, the process will run through without these fittings

Upon starting the Show 3D command (S3D) the drawing immediately switches to SE isometric, reports no errors but no 3D piping is visible.  Even newly drawn pipe won't elevate.

Drawing successfully elevated to 3D. No errors were found

Related HydraCARD: #853

https://hydracards.hydratecinc.com/cards/card-853

After buiding your 3D risers, raising to 3D, exporting to a Persistent Model and Navisworks successfully, your 3D riser is missing, with the exception of the skipoles

Your layers are on and the 3D_DETAIL layer is present, unlocked, thawed and visible, you just can't see the pipe and fittings.  The one customer reporting this said they disappear if the drawing is closed then re-opened.  They'll be visible in viewports as well, just not in 2D view.

See this related HydraCARD also;  https://hydracards.hydratecinc.com/cards/card-1144

Primary calc results are shown, and when selecting OK to continue back to the calc input screen, the two messages below are displayed, twice;

"The designated source node was not found in the list of pipes" OK

"Calculation failed for an unknown reason" OK

Process Error Hydcalc

When trying to change pipe types, the selection window is blank

When starting the Pretty Pipes command, you get an Unhandled Exception error including 'Could not find a part of the path'

Another error may mention blockoffsets.dat

Command is run, but nothing appears to happen. May get Nil message

Double-Clicking on a riser nipple, or using the Edit Riser Nipple command (ERN) briefly displays the edit riser nipple dialog, which then closes

During the AutoCALC process, it gets hung up at step 5a.3b.

Re-Ordering Pipe Paths - Phase 2

Upon calculating a file, the error message, "Failed to launch C:\HES\Hydratec for revit\programs\calcdiagnose.exe" pops up.

Was preceeded by these messages;

Plus this;  Number of Loops -1 and or Nodes with undesignated elevations

When connecting a hard pipe armover to a flexible sprinkler connection (FSC), the flex hose doesn't continue straight, instead it immediately turns 90° before curving back and down to the sprinkler head.

Even with setting the connection to OVER-DOWN

When selecting a vertical pipe/riser nipple hydrapipe, the PROPERTIES window shows "no selection" instead of "hydrapipe"

You may notice that you cannot use the 'change length' command (CL) or cannot rotate riser nipple (RRT)

Running HydraCAD commands do not work in one drawing, but will work in a different drawing in the same session of AutoCAD/HydraCAD.

Inserting a pipe dimesion gives an 'unknown command' message.

Hydrapipe - vertical pipe issue Switching to Edit Mode leaves HydraPipes in Hydrapipe layer. Then when trying to show system model you get an AutoCAD message box "Please Switch to Edit Mode. Then try again." Switch to Edit....

When using 'Publish selected layouts' or doing a batch plot in AutoCAD 2024, the riser nipple/vertial pipe does not display correctly.  It'll either be missing outright or a proxy bounding box will be in its place.  If you plot a single sheet, it works fine.

AutoCAD 2024 batch plot

'

AutoCAD 2024 single plot

When attempting to create a 3D model, you get the error; Please switch to System Model to Annotate Drops and Sprigs plus

System.NullReferenceException: Object reference not set to an instance of an object

at HCADexports.RevitConversion.create_hydrapipes_from_db()

at HCADexports.RevitConversion.create_hydrafittings_from_db(List'1 pipes, List'1 heads)

When opening HydraCAD, you get this error message or something similar;

AutoCAD Warning

The following shortcuts in the search were invalid and ignored:

After clicking OK, HydraCAD will open up, albeit very slowly, and almost every step will take an significant amount of time, for example 45 seconds to start a new drawing or to size a pipe

When trying to insert a sprinkler head, this window pops up;

Pick head insertion point. Pick any point besides endpoint to break into pipe. Can't find file in search path

*Invalid*
