Standalone (Hydracalc)
Total: 77
Page:
* On smaller devices swipe left to view hidden table data
Ribbon/Toolbar (Software) | Button | Function | Error Type | Description | ||
---|---|---|---|---|---|---|
Ribbon/Toolbar (Software) | Button | Function | Error Type | Description | ||
View (card-1258) | HydraCALC (Standalone) | Print Final | None | When printing final, you get this error message "Error during Cover Sheet print, possibly due to missing .DAT file" |
||
View (card-1214) | HydraCALC (Standalone) | Fittings | Right-Click | Runtime Error | When right-clicking the Fittings column, you get a MiscFunc Run-time error 5, Invalid procedure or argument |
|
View (card-1192) | HydraCALC (Standalone) | Print Final | None | Printing a final calculation to PDF creates a blurry or pixelated cover sheet logo
|
||
View (card-1169) | HydraCALC (Standalone) | Calculate | Calculation Results | Other | When running a calculation, the results window pops up but just stalls or hangs there. The window will eventually say (Not Responding) and you can't click out of it
|
|
View (card-1162) | HydraCALC (Standalone) | Print Final | Results | None | After adding a Secondary Curve to your water supply, you decide you don't want it, it's impossible to remove the secondary curve value.
|
|
View (card-1157) | HydraCALC (Standalone) | Print Final | None | Runtime Error | When trying to [Print|Final] in HydraCALC, the user gets a Runtime Error 5, "Invalid Procedure Call or Argument". HydraVIEW does not open and after clicking OK, HydraCALC crashes.
|
|
View (card-1145) | HydraCALC (Standalone) | Utilities | Alter Pipe | Saving Data | Runtime 76 | When editing and saving data for pipes, fittings, or flexible connections, you get a Run-time error 76, Path not found error |
|
View (card-1118) | HydraCALC (Standalone) | None | None | Bad Location Of K-Factor | Bad location of K-Factor |
|
View (card-1108) | HydraCALC (Standalone) | Calculate | Calculating | Could Not Initiate Process | Trying to run a calculation, you get the error; Could not Initiate Process called for by: (name of the problem file), ie. HydCalc.exe or Miscfunc.exe
|
|
View (card-1077) | HydraCALC (Standalone) | Print Final | Results | Discrepancy | Reviewing the results you notice a discrepancy between the k-factor of an equivalent k versus a sprinkler head using that equivalent k-factor
In the example below, EQ02 has a k-factor of 5.37. Reference point 1 is supposed to use the k-factor of EQ02 (5.37) but in fact is using a different value (5.36).
|
