All Cards
* On smaller devices swipe left to view hidden table data
| Ribbon/Toolbar (Software) | Button | Function | Error Type | Description | ||
|---|---|---|---|---|---|---|
| Ribbon/Toolbar (Software) | Button | Function | Error Type | Description | ||
| Card 1362 View | HydraCALC Sizer (Standalone) | Open | None | Runtime Error | When opening HydraCALC SIZER, you get the error; Run-time error '53': File not found
|
|
| Card 1361 View | Listing (AutoCAD Based) | Start Autolist | None | Error With Drop/Sprig | After starting the AutoLIST process, you get an error saying, "Error with Drop/Sprig annotation... This one will be displayed"
After clicking OK, HydraLIST opens but you won't see any cut lengths of your sprigs and drops in the layer DropSprigTextCL |
|
| Card 1360 View | Installation (AutoCAD Based) | None | None | None | During the install of HydraCAD, you get an error, "Setup Needs the Next Disk, Please insert disk 1 that contains the file data2cab"
|
|
| Card 1359 View | Add-Ins (Revit Based) | HydraCAD | Retrieve HydraCAD Revit MEP Content | Command Failure For External Command | Revit could not complete the external command... Revit encountered a Attempt to modify the model outside of transaction
|
|
| Card 1358 View | 3D Modeling (AutoCAD Based) | S3D - Raise to 3D | None | None | When closing a drawing in 3D, and later re-opening and returning to 2D, some of the drawing symbols show up looking like outlines (Hangers, Sprinklers, etc)
|
|
| Card 1357 View | Launching HydraCAD (AutoCAD Based) | None | None | None | HydraCAD Critical Error... Visual Lisp not available
|
|
| Card 1356 View | HydraCAD (Revit Based) | Hangers | None | None | Error appears when opening Hangers Failed to load the following families: z_Pipe Elevation Marker
|
|
| Card 1355 View | All (Revit Based) | Setup | None | None | Revit could not complete the external command... Missing file
|
|
| Card 1354 View | HydraTools (AutoCAD Based) | Fluid Delivery Time (FDT) | None | None | Runtime Error 5 running FDT command on Metric drawing
|
|
| Card 1353 View | Sprinklers (AutoCAD Based) | Select Sprinkler | Head Selector | None | Blacked out cells in Head Selector dialog
|
|
| Card 1352 View | Calculations (AutoCAD Based) | Start Autocalcs | None | Unhandled Exception | After clicking the Start AutoCALCs (SAL command) button but BEFORE the AutoCALC Setup window, you get the error;
Unhandled exception has occurred in a component in your application. If you click Continue, the application will ignore this error and attempt to continue. The input string '1◆' was not in a correct format. |
|
| Card 1351 View | Display (AutoCAD Based) | None | None | None | No inch marks (“) after the pipe diameter or there are but you prefer to remove them
|
|
| Card 1350 View | Opening a Drawing (AutoCAD Based) | None | None | None | After opening AutoCAD and a drawing, you have a dead area where you can't draw nor does anything display. Usually next to a compressed palette. Note in the image below how the crosshairs do not extend to this area.
|
|
| Card 1349 View | HydraLIST (Standalone) | None | None | None | Yellow part numbers that do not list
|
|
| Card 1348 View | Piping (AutoCAD Based) | Manual Cut Lengths | None | Bad Argument | When using Manual Cut Lengths on sprigs, after selecting the sprig text, this error appears: "Error: bad argument type: lselsetp nil" This error can also appear when selecting drops |
|
| Card 1347 View | HydraLIST (Standalone) | Save | None | None | When saving the file, no hvuf file gets created, and run-time error 3021 appears
|
|
| Card 1346 View | Display (AutoCAD Based) | None | None | None | Line / Main tags are blocking items behind the text / tags are not transparent
|
|
| Card 1345 View | HydraCAD (Revit Based) | Tag Pipes | None | Command Failure For External Command | Revit could not complete the external command... Revit encountered a Attempt to modify the model outside of transaction...
|
|
| Card 1344 View | HydraCAD (Revit Based) | RTS Points | None | None | Pop-up immediately after selecting RTS Points
|
|
| Card 1343 View | HydraCALC (Revit Based) | Select Remote Area | None | None | Command Failure for External Command... Object reference not set to an instance of an object
|
|
